Haynes Manuals

Jaguar XJ6 XJ12 Series 1, 2 & 3 & XJS Wiring Diagrams

$59.00

  • Free shipping on orders over $79.00
  • Despatched in 1-2 business days
  • The original print manual

Description

Jaguar XJ Series>Complete vehicle wiring diagrams

What's covered:

  • Series 1 1968-1974 - XJ6 2.8L, 4.2L. XJ12 5.3L.
  • Series 2 1974-1978 - XJ6 3.4L, 4.2L. XJ12 5.3L. XJ-C 4.2L, 5.3L.
  • Series 3 1978-1989 - XJ6 3...

More Information

  • Coverage

    Jaguar XJ Wiring Diagrams Complete vehicle wiring diagrams covers -

    • Series 1 1968-1974 - XJ6 2.8L, 4.2L. XJ12 5.3L.
    • Series 2 1974-1978 - XJ6 3.4L, 4.2L. XJ12 5.3L. XJ-C 4.2L, 5.3L.
    • Series 3 1978-1989 - XJ6 3.4L, 4.2L.
    • XJ12 5.3L.
    • XJ-S 1975-1989 - V12 5.3L, 6.0L,
    • XJ-S HE 5.3L.
    • XJ-S 3.6L, 4.0L
