Wondering which brake fluid to put in your Mazda MX-5? Thinking about changing the engine oil and filter? You've come to the right place. Haynes has all the routine maintenance facts you need, whether it's the right type of coolant for your MX-5, what type of engine oil to use, the power steering fluid and more... all of the relevant Mazda MX-5 parts and Mazda Miata service specs are here.
Here's our quick reference guide to the routine maintenance tasks for the Mk1 and Mk2 Mazda MX-5 made from 1989 to 2005, all of which you can do yourself at home. If you need more guidance, or step-by-step instructions, check out the online and printed versions of the Mazda MX-5 Owner's Workshop Manual.
Mazda MX-5 Oil Change
| MX-5 Engine Oil Type |
10W/40 multigrade |
| MX-5 Engine Oil Capacity (including oil filter) | 3.7 litres (1.6 litre engines) |
| 3.8 litres (1.8 litre engines) |
|
| MX-5 Oil Drain Plug Torque |
35 Nm |
Mazda MX-5 Transmission Fluid Change
| MX-5 Manual Transmission Fluid Type |
75W/90 GL4 or GL5 |
| MX-5 Final Drive Fluid Type |
SAE 90 GL5 |
| MX-5 Manual Transmission Fluid Capacity |
2.0 litres (5-speed ) |
| 1.8 litres (6-speed ) |
|
| MX-5 Final Drive Fluid Capacity |
0.65 litre (<1993 models) |
| 1.0 litre (1994> models) |
|
| MX-5 Manual Transmission Fluid Drain Plug Torque |
44 Nm (5-speed) |
| 35 Nm (6-speed) |
|
| MX-5 Manual Transmission Fluid Filler/Level Plug Torque |
35 Nm |
| MX-5 Final Drive Drain Plug Torque |
44 Nm |
| MX-5 Final Drive Filler/ Level plug Torque |
44 Nm |
Mazda MX-5 Coolant Renewal
| MX-5 Coolant Type | 50/50 mix of water and Ethylene glycol based antifreeze |
| MX-5 Coolant System Capacity |
6.0 litres |
Mazda MX-5 Power Steering and Brake Fluid Renewal
| MX-5 Power Steering Fluid |
Dexron II |
| MX-5 Brake And Clutch Fluid Type |
DOT 4 brake fluid |
Mazda MX-5 Torque Specs
| MX-5 Wheel Nuts | 110 Nm |
| MX-5 Front Caliper Guide Pin Bolts |
50 Nm (all except 270 mm diameter discs) |
| 26 Nm (270 mm diameter discs) |
|
| MX-5 Front Caliper Mounting Bracket Bolts |
65 Nm |
| MX-5 Rear Caliper Guide Pin Bolts |
50 Nm |
| MX-5 Rear Caliper Bracket Bolts |
50 Nm |
| MX-5 ABS Wheel Speed Sensor Bolts |
20 Nm |
Check out these MX-5 NC common problems
Mazda MX-5 Maintenance Schedule
Planning to work on your Mazda MX 5 or Mazda Miata? These are the minimum intervals recommended by us for MX-5s driven daily. If you wish to keep your MX5 roadster in peak condition at all times, you may wish to perform some of these procedures more often. We encourage frequent maintenance, since it enhances the efficiency, performance and resale value of your MX-5.
Do you live in a harsh climate, where it's particularly dusty or by the sea? Maybe you frequently drive your MX-5 at slow speeds (idling in traffic) or on short journeys? If so, more frequent maintenance intervals are recommended.
What to check on a Mazda MX-5 every week or 400km, whichever comes first
- Check the engine oil level
- Check the coolant level
- Check the screenwash fluid level
- Check the brake fluid level
- Check the clutch fluid level
- Check the power steering fluid level
- Check the tyres and tyre pressures
- Check the condition of the battery
- Check the condition of the wiper blades
What to check on a Mazda MX-5 every 10,000km or 6 months, whichever comes first
- Renew the engine oil and filter*
- Check and adjust the brake pedal height
- Check and adjust the clutch pedal height
*Note: Oil and filter changes are good for the engine and we recommend that the oil and filter are renewed frequently, especially if the MX-5 is used on a lot of short journeys
What to check on a Mazda MX-5 every 19,000km or 12 months, whichever comes first
In addition to the items listed above, carry out the following:
- Check the condition of the MX-5's auxiliary or serpentine drive belt
- Check under the bonnet for fluid leaks and hose condition
- Check the underbody and all fuel/brake lines
- Check the condition of the MX-5's brake pads and discs
- Check the condition of the MX-5's driveshaft joints and gaiters
- Check the MX-5's steering and suspension components for condition and security
- Check the underbody sealant for damage
- Check the MX-5's exhaust system and its mountings
- Check and if necessary adjust the MX-5's handbrake
- Lubricate all hinges and locks
- Carry out a road test of the MX-5
- Check the condition of the MX-5's seat belts
What to check on a Mazda MX-5 every 38,000km or 2 years, whichever comes first
In addition to the items listed above, carry out the following:
- Renew the MX-5's air filter*
- Renew the MX-5's spark plugs and check the condition of the HT leads
- Renew the MX-5's brake fluid
- Renew the engine coolant
- Check the PCV valve
- Check the evaporative loss system
- Renew the MX-5's fuel filter
- Check the manual transmission oil level
- Renew the final drive fluid
*Note: If the MX-5 is used in dusty conditions, the air filter should be renewed more frequently.
What to check on a Mazda MX-5 every 77,000km or 4 years, whichever comes first
In addition to the items listed above, carry out the following:
- Renew the MX-5's timing belt*
- Renew the manual transmission oil
- Renew the remote control battery
- Check the valve clearances
*Note: Although the normal interval for the Mazda MX-5's timing belt renewal is 85,000km, Haynes strongly recommends that the belt is renewed at 77,000km. Bear in mind that severe engine damage will result if the belt breaks.
