Air filter change Volkswagen Golf 2010 - 2011

Air filter change Volkswagen Golf 2010 - 2011

3 minute read

Volkswagen Golf

2010 - 2011
Time
5 to 45 minutes
Difficulty
Note: On four-cylinder BPY and five-cylinder engines, the air filter is in the engine cover

Four-cylinder timing belt engine (BPY)

1 Release the intake hose clamps at the rear of the engine cover and disconnect the intake hose from the Mass Air Flow (MAF) sensor (see below)
2 Engine cover details - five-cylinder engine shown, four-cylinder BPY models similar: 1 Intake hose clamp. 2 Mass Air Flow (MAF) sensor electrical connector. 3 Smaller hose. 4 Intake air duct screws
3 Disconnect the Mass Air Flow (MAF) sensor electrical connector
3 Remove the fresh air intake air duct mounting screws at the front of the engine cover
4 Lift the engine cover up from the right side of the ballstuds, then the left side, and remove the cover
5 Place the cover upside down on a bench and remove the filter housing mounting screws
6 Rotate the housing up and unhook it from the engine cover, then remove the filter from the housing
7 Clean the inside of the air filter housing with a damp cloth
8 Installation is the reverse of removal

Four-cylinder timing chain engines (CBFA and CCTA)

Note: To remove the engine cover, lift the cover up and off of the ballstuds
1 Release the air guide top cover clips and remove the top cover
2 Release the air guide lower clips and remove the guide
3 Remove the fasteners that secure the cover of the filter housing. On models so equipped, also detach the smaller hose from the front of the filter housing
4 Lift the cover up and remove the air filter element
5 Clean the inside of the air filter housing with a damp cloth
6 Installation is the reverse of removal

Five-cylinder engines

1 Release the intake hose clamp from the engine cover and disconnect the intake hose
2 Disconnect the Mass Air Flow (MAF) sensor electrical connector. On models so equipped, also detach the smaller hose from the front of the filter housing
3 Remove the fresh air intake air duct mounting screws at the front of the engine cover
4 Lift the cover up from the right side off of the ballstuds, then the left side, and remove the cover
5a Place the cover upside down on a bench and remove the filter housing mounting fasteners (see below)
5b Air filter housing fastener locations - five-cylinder engine shown, four-cylinder BPY models similar
6 Rotate the housing up, then remove the filter element
7 Clean the inside of the air filter housing with a damp cloth
8 Installation is the reverse of removal
