Time
0.2 hours
Difficulty
Air filter location
Undo all the retaining fixings on this cover to access the air filter - use 10mm socket
No carefully remove the cover
Undo the two retaining bolts - use a 10mm socket
Remove the seal
Remove the metal moulding
Undo the two Phillips retaining fixings on the air filter body
Carefully lift away the air filter box
View of the air filter cartridge
Air filter in position. Now separate the air filter for inspection
Clean off any debris on the surface of the filter. Replace with new filter if heavily contaminated
Check air filter box for debris. Clean out if required. Replace the air filter
Reassemble the air filter housing
